🔹 THÔNG SỐ KỸ THUẬT
- Manufacturer: Nuvoton Technology Corporation of America
- Core Processor: 8051
- Core Size: 8-Bit
- Speed: 16MHz
- Connectivity: I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, I²S, POR, PWM, WDT
- Number of I/O: 18
- Program Memory Size: 18KB (18K x 8)
- Program Memory Type: FLASH
- EEPROM Size: 4K x 8
- RAM Size: 1K x 8
- Voltage – Supply (Vcc/Vdd): 2.4 V ~ 5.5 V
- Data Converters: A/D 8x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Package / Case: 20-TSSOP (0.173″, 4.40mm Width)
